1. Product overview

It is a long-distance live-state visualization device specially developed for 6kV-220kV overhead transmission lines, which solves the problem of insufficient identification of traditional indicators in strong light, haze, night and other environments, effectively preventing accidents of climbing live towers by mistake.

2. Functions & features

· Accurate monitoring and wide range

It can accurately detect the live status of outdoor high-voltage cables with voltage classes of 6kV, 10kV, 35kV, 110kV, and 220kV to ensure operational safety.

· Super visibility

It uses ultra-high brightness LED indicator lights to display the live status clearly, making it identifiable even in complex environments.

· Strong anti-interference ability

It’s equipped with built-in anti-electromagnetic interference technology to ensure stable operation in strong electromagnetic environments.

· Durable in all weather conditions

It’s designed with the overall epoxy sealing infusion, so it is maintenance-free and has the performance of resisting harsh natural environments and lightning strikes.

· Ultra-long battery life

Dual power mode: It’s powered by solar panels and high-voltage electric fields, with a continuous working life of over 50,000 hours outdoors.

· Easy installation

It’s equipped with a spring clip that can be directly fixed to overhead cables without the need for power outage during installation.

3. Technical specifications

1. Scope of application: 6kV, 10kV,   35kV,   110kV and 220kV

2. Working temperature:- 40℃ ~ +70℃

3. Power supply method: solar panel+lithium battery pack

4. Outdoor working life: >50,000 hours

5. Flash starting voltage: 50% of rated voltage value

6. Flashing frequency: When there is high voltage is available, it flashes once every 1.5 seconds; It does not flash when there high voltage is not available.

7. Application place: Suitable for outdoor overhead high-voltage cables, the bare or insulated high-voltage lines within a diameter range of 12-35mm.

8. Visual range: No less than 15m.

4. Applications

It’s widely used in high-voltage overhead cable.
